KS-8MF Technical Specifications: Comprehensive Performance Data for Engineering Evaluation

KS-8MF Technical Specifications: Comprehensive Performance Data for Engineering Evaluation

Making informed equipment decisions requires access to detailed, accurate technical information. These comprehensive KS-8MF technical specifications provide engineering teams with the critical data needed to evaluate compatibility, plan integration, and forecast performance in specific production environments.

Detailed Performance Specifications

• Mechanical Dimensions

  • Overall Size: 1500mm (L) × 520mm (W) × 950mm (H)

  • Effective Conveyor Width: Adjustable 50-400mm

  • Weight Capacity: Maximum 5kg distributed load

• Electrical Requirements

  • Power Supply: AC 220V ±10%, 50/60Hz, Single Phase

  • Power Consumption: 350W maximum

  • Control Voltage: 24V DC

  • Safety Standards: CE, UL certified

• Performance Parameters

  • Conveyor Speed: 0.5-2.5 M/min (programmable)

  • PCB Thickness Range: 0.4-4.0mm

  • Positioning Accuracy: ±0.5mm

  • Noise Level: <65 dB in operation

• Environmental Specifications

  • Operating Temperature: 5-40°C

  • Storage Temperature: -20-60°C

  • Humidity Range: 30-70% RH (non-condensing)
