YAMAHA YSM20R Pick And Place Machine

Model YAMAHA YSM20R

Brand YAMAHA

Consult immediately

Send inquiry

DetailConpanyFAQ

Specification of YAMAHA YSM20WR Placement Equipment Modular SMT Machine

Model	YSM20R TypePV	YSM20R TypeSV	YSM20WR
Applicable PCB	Single lane L810 x W490 to L50 x W50 Dual stage Note: For X-axis 2-beam option only 1PCB conveyance: L810 x W490 to L50 x W50 2PCB conveyance: L380 x W490 to L50 x W50		Dual lane Note 1 Same type PCBs: L810 x W356 to L50 x W50 Different type PCBs: up to L810 x W662 Note 2 Same type PCB: L810 x W280 to L50 x W500 Different type PCBs: up to L810 x W510
Head / Applicable components	High-Speed Multi (HM) Head Note 3: 0201 to W55 x L100mm, Height 15mm or less Odd-shaped components (FM: Flexible Multi) head: 03015 to W55 x L100mm, Height 28mm or less	High-Speed Multi (HM) Head: 03015 to W55 x L100mm, Height 15mm or less Odd-shaped components (FM: Flexible Multi) head: 03015 to W55 x L100mm, Height 28mm or less	High-Speed Multi (HM) Head Note 3: 0201 to W55 x L100mm, Height 15mm or less Odd-shaped components (FM: Flexible Multi) head: 03015 to W55 x L100mm, Height 28mm or less
Mounting capability (under optimum conditions as defined by Yamaha Motor)	X axis 2-beam: High-speed multi-purpose (HM: High-speed Multi) head x 2 95,000CPH	X axis 2-beam: High-speed multi-purpose (HM: High-speed Multi) head x 2 90,000CPH	X axis 2-beam Note 1: High-speed multi-purpose (HM: High-speed Multi) head x 2
Mounting accuracy	±0.035mm (±0.025mm) Cpk≧1.0 (3σ) (under optimum conditions as defined by Yamaha Motor when standard evaluation materials are used)
Number of component Types	Fixed plate: Max. 140 types (conversion for 8mm tape feeder) Feeder carriage exchange: Max. 128 types (conversion for 8mm tape feeder) Trays for 30 types (Fixed type: max., when fitted with sATS30) and 10 types (Carriage type: max., when fitted with cATS10)
Power supply	3-Phase AC 200/208/220/240/380/400/416V +/-10% 50/60Hz
Air supply source	0.45MPa or more, in clean, dry state
External dimension (excluding projections)	L 1,374 x W 1,857 x H1,445mm (Main unit only)		L 1,374 x W 2,110 x H1,445mm (Main unit only)
Weight	Approx. 2,050kg (Main unit only)		Approx. 2,500kg (Main unit only)
