Plasma panel cleaning machine
TECHNICAL PARAMETER
Framework main structure | Main body sheet metal+customized precision aluminum parts |
Dimensions (MM) | L800*W1150*H1550 |
By PCB size (MM) | 60*60～450*350 |
Working voltage/current | AC220V、50、60HZ/0.1KV |
Gas source/consumption | 6MPa / <40L/min |
Transport Direction | L-R & R-L |
Transmission altitude | 900+50/-20mm |
Transmission power | step motor |
cleaning device | High speed spiral cleaning |
TRANSPORT BELT | 5MM flat belt |
processing speed | 1-40 meters per minute |
Transmission fixed edge | Relying on the operating surface |
control system | Panasonic PLC |
Control panel | 7-inch color touch screen |
communication model | International Standard SMEMA Interface |
Track adjustment | Ball screw+motor CNC adjustment |
Successful Experience:
1. We provide the best full-line equipment solutions for customers in different industries.(such as : chip industry, consumer electronics industry, aerospace technology, automated robotics and other industries)
2. We provide machine installation services for oversea customers.
3. We Provide Machines & Clean Room One- Stop Layout and Solution.
4. KINGSUN’s engineering team is proficient in English and Technology, no communication issues.
For SMT Factory Setup, We Can Do for You:
1. We can provide SMT full line solutions and debugging services.
2. We can provide technical personnel training for customers.
3. We can provide daily maintenance & repair service.
